Ingersoll Rand
Model: D Series
Air Chipping Hammer
This rugged tool features the best power to weight in its class for increased job site productivity. Additionally, this unit features a convenient "D" shaped handle and outside trigger, along with a strong four-bolt backhead for easy serviceability.
Available in 2", 3" and 4" stroke versions.
- Time tested valve design
- Die cast aluminum handle
- Directional exhaust
- Tease throttle
- Over-molded steel collar
| This Tool Has A .580 Hex Shank x Oval Collar |
|
||
| Model | Product Detail | Part Number |  |
| 2DA1SA | 2" Stroke x 0.580 Hex | 2DA1SA | |
| 3DA1SA | 3" Stroke x 0.580 Hex | 3DA1SA | |
| 4DA1SA | 4" Stroke x 0.580 Hex | 4DA1SA | |
| This Tool Has A .680 Round Shank x Oval Collar |
|
||
| Model | Product Detail | Part Number | |
| 2DA2SA | 2" Stroke x 0.680 Round | 2DA2SA | |
| 3DA2SA | 3" Stroke x 0.680 Round | 3DA2SA | |
| 4DA2SA | 4" Stroke x 0.680 Round | 4DA2SA | |
| IR "D" Series | ||||||||
| Model - P/N: | 2DA1SA | 2DA2SA | 3DA1SA | 3DA2SA | 4DA1SA | 4DA2SA | ||
| Chuck/Shank Size (inches) |
.580 Hex | .680 Rnd | .580 Hex | .680 Rnd | .580 Hex | .680 Rnd | ||
| Retainer Type |
Lock-spring (plain arrow) |
Lock-spring (plain arrow) |
Lock-spring (plain arrow) |
Lock-spring (plain arrow) |
Lock-spring (plain arrow) |
Lock-spring (plain arrow) |
||
| Blows/Min. [/sec.] | 2200 [37] | 2200 [37] | 1900 [32] | 1900 [32] | 1600 [27] | 1600 [27] | ||
| Bore (inches) |
1-1/8 | 1-1/8 | 1-1/8 | 1-1/8 | 1-1/8 | 1-1/8 | ||
| Stroke (inches) |
2 | 2 | 3 | 3 | 4 | 4 | ||
| Air Consumption @ Load cfm (L/min) |
28 (793) | 28 (793) | 31 (878) | 31 (878) | 34 (963) | 34 (963) | ||
| Air Inlet NPT (inch) |
7/8 | 7/8 | 7/8 | 7/8 | 7/8 | 7/8 | ||
| Min Hose Size I.D. (inch) |
1 | 1 | 1 | 1 | 1 | 1 | ||
| Weight (lbs.) | 11.8 | 11.8 | 13 | 13 | 14 | 14 | ||
| Length w/o accy (inches) |
13.75 | 13.75 | 17 | 17 | 18 | 18 | ||
| Chipping Hammer Bits | |||||
| Longer Lengths Available for Most Tools - Call: 800‐241‐9669 | |||||
| Points & Chisels | Under Collar Length (inch): |  Oval Collar Hex Shank Part Number: |  Oval Collar Round Shank Part Number: |  Round Collar Hex Shank Part Number: |  Round Collar Round Shank Part Number: |
Moil Point |
12" | OCHS-12P | OCRS-12P | RCHS-12P | RCRS-12P |
| 18" | OCHS-18P | OCRS-18P | RCHS-18P | RCRS-18P |
|
| 24" | OCHS-24P | OCRS-24P | RCHS-24P | RCRS-24P |
|
Narrow Chisel |
12" | OCHS-12C | OCRS-12C | RCHS-12C | RCRS-12C |
| 18" | OCHS-18C | OCRS-18C | RCHS-18C | RCRS-18C |
|
| 24" | OCHS-24C | OCRS-24C | RCHS-24C | RCRS-24C |
|
2in. Wide Blade Chisel |
12" | OCHS-12C2 | OCRS-12C2 | RCHS-12C2 | RCRS-12C2 |
| 18" | OCHS-18C2 | OCRS-18C2 | RCHS-18C2 | RCRS-18C2 |
|
| 24" | OCHS-24C2 | OCRS-24C2 | RCHS-24C2 | RCRS-24C2 |
|
3in. Wide Blade Chisel |
12" | OCHS-12C3 | OCRS-12C3 | RCHS-12C3 | RCRS-12C3 |
| 18" | OCHS-18C3 | OCRS-18C3 | RCHS-18C3 | RCRS-18C3 |
|
| 24" | OCHS-24C3 | OCRS-24C3 | RCHS-24C3 | RCRS-24C3 |
|
4-1/2in. Wide Clay Spade |
10" | OCHS-CS | OCRS-CS | RCHS-CS | RCRS-CS |
1 Pc. All-Steel Bushing Tool |
8" | OCHS-BT | OCRS-BT | RCHS-BT | RCRS-BT |
| Longer Lengths Available for Most Tools - Call: 800‐241‐9669 | |||||
Coming soon! Please call for safety data for this tool.
Coming soon! Please call for additional pictures available for this tool.
